| Specification | Details |
| Machine Type | Wax Coating Machine |
| Application | Production of wax-coated paper (wax paper, greaseproof, or moisture-resistant wrapping paper) |
| Compatible Substrates | Various types of paper |
| Paper Type | Customizable based on customer requirements |
| Coating Material | Wax (typically paraffin-based) |
| Coating Direction | Single-sided (double-sided coating available upon request) |
| Unwinding Unit Included | Included |
| Rewinding Unit Included | Included |
| Tension Control Unit | Included |
| Effective Coating Width | 1000 mm (customizable from 600 mm to 2000 mm) |
| Maximum Roll Width | 1100 mm (upgradable to 2200 mm) |
| Maximum Operating speed | 150 meters/min (upgradable to 300 meters/min) |
| Max. Unwinding Roll Diameter | 600 mm (customizable up to 1000 mm) |
| Max. Rewinding Roll Diameter | 600 mm (customizable up to 1000 mm) |
| Heating Method | Hot oil heating (optional: electric or gas heating available upon request) |
| Coating Uniformity | ±3 µm (microns) |
| Edge Cutting Accuracy | 1.5 mm |
| Body Material | Steel and Stainless Steel |
| Delivery Time | 90 days |
| Software & Control Interface | PLC with HMI touchscreen |
| Approximate Machine Weight | 4tons |
| Machine Dimensions | 4.5 × 2.2 × 2.0 meters (may vary depending on configuration) |
Need a Custom Solution?
Get Your One-on-One Consultation
Struggling to find the perfect machine that fits your unique factory layout or production goal?
Wax Coating Machine for Paraffin Wax Paper and Greaseproof Paper
The wax coating machine is an essential industrial solution for producing greaseproof, moisture-resistant, and food-safe waxed papers. Using melted paraffin wax, natural beeswax, or plant-based waxes, this machine evenly coats Kraft, sulfite, or semi-transparent papers using methods such as roll coating, blade coating, or spray coating.
Ideal for manufacturing single- or double-sided wax paper, it is widely used in the food packaging industry (for burgers, cheese, sandwiches, chocolate), cosmetics, industrial metal protection, and handcraft applications. The system features precise temperature control, web tension management, and cooling rollers to ensure uniform, high-quality coating with minimal waste.
Our Wax Coating Machine is the pinnacle of technology for producing high-quality paraffin wax paper and greaseproof paper. Engineered for efficiency and precision, this machine is your essential partner in the food packaging, retail, and industrial sectors. With its advanced features and robust construction, the Wax Coating Machine guarantees a superior, uniform coating, making your products ideal for preserving freshness and protecting against moisture and grease.
With customizable options for coating width, speed, and wax type, this machine enables scalable, cost-effective, and eco-conscious production of wax-coated paper in various formats.
Key Features and Technical Specifications
- Exceptional Versatility: Wax Coating Machine is meticulously designed to work with a wide range of paper types, delivering a flawless coat of paraffin wax or other specialized coatings.
- Precision Coating: Our state-of-the-art coating mechanism ensures a smooth, even, and consistent wax application across the entire paper surface, eliminating waste and producing a professional finish.
- High-Speed Production: With its impressive processing speed, the Wax Coating Machine maximizes your output, enabling you to meet high demand and enhance your production efficiency.
- User-Friendly Interface: The intuitive control panel enables operators to easily manage settings, monitor the process, and ensure optimal performance with minimal training.
Why Choose Our Wax Coating Machine?
Investing in our H2 Wax Coating Machine means choosing a partner committed to quality and performance. Our advanced coating machinery solutions are a testament to our expertise in manufacturing. As part of our comprehensive range of converting machinery, this machine is built to last, providing you with a reliable and profitable solution for years to come.
We are dedicated to providing machines that are not only technologically superior but also offer a competitive edge in the market. Contact us today to learn how the H2 Wax Coating Machine can transform your production line.
